View All Models
Make: Weichai Euro 3 Turbo charged Intercooled
Model Confirguration: WP7.270 E30
Max Power - Kw @ r/min: 199/2300
Max Torque - N.m @ r/min: 1100/1200~1600
HP: 270
Cylinder: 6 Inline
Water Cooled: Yes
Direct Injection: Yes
Engine Driven P.T.O: No
Displacement (I): 7,14
Compression Ratio: 18:01
Service: Dual circuit air brakes
Emergency / Parking: Spring potential brake
Auxiliary: ABS & EVB
Size and ply rating: 315-80R22.5 incl. spare wheel
Type: VR4/10D-7.5(ABS) Drum Brake
Suspension: Non-free standing stabilization leaf spring, hydraulic shock absorber, transverse stabilizer
Type: HL8/02D-10/4.11(ABS), Hypoid and BPW 9T ECO PLUS Tag axle
Suspension: Stabilizator suspension, hydraulic shock absorber, Transverse stabilizer, and BPW Air suspension Tag axle
Alternator: 70Amp
Starter Motor: 5.75kW
Batteries: 2 x 12V - 135AH
Gradeability @ GVM: 20% @GVM
Max Geared Road Speed: 110km/h (Limited to 80km/h)
Final Drive Ratio: 4,11
Make / Type / Size: GFX 420mm single
Operation: Single dry frictional disc, Diaphragm spring, pushing type
New Vehicle: 3 years/300 000km (South Africa only)
Make/Model: 8JS118TB-B+QH50
No Gears: 8
Synchromesh or Constant Mesh: Synchromesh
Transfer Box:N/A
P.T.O: Yes
Overall Length (OL): 10 600
Overall Width (OW): 2 495
Overall Height (OH): 2 905
Front Overhang (FOH): 1 435
Rear Overhang (ROH): 2 475
Wheel Base (WB): 6 200
Bumper to Back of Cab (BBC):1 880
Cab to Rear Axle / unit (CA): 5 670
Turning Radius (TR):10 000
Fuel Tank Capacity (FTC): 400 LTR Aluminum
Manufacturers Gross Vehicle Mass (GVM): 25 000
Manufacturers Gross Combination Mass (GCM): 28 000
Manufacturers Front Axle Mass (GA): 7 500
Manufacturers Rear Axle Mass (GAU): 19 000
Permissible Maximum Vehicle Mass (V): 25 000
Permissible Maximum Front Axle Mass (AF): 7 500
Permissible Maximum Rear Axle Mass (AR): 18 000
Unladen Front Axle Mass (UF): 3 830
Unladen Rear Axle Mass (UR): 3 505
Total Unladen Mass (UT):7 335
Permissible Max Drawing Vehicle Mass (D/T): 28 000
Day Cab: Hydraulic Tiltable Cab
SPECIFICATIONS
Additional Applications
| Models | Variant | Price |
|---|---|---|
| 2527 LWB 6x2 |
Chassis Cab | R P.O.A |
