Make: Weichai Euro 2 Intercooled
Model Confirguration: WP 10-340 E32
Max Power - Kw @ r/min: 250/2200
Max Torque - N.m @ r/min: 1350/1200-1600
HP: 350
Cylinder: 6 Inline
Water Cooled: Yes
Direct Injection: Yes
Engine Driven P.T.O: No
Displacement (I): 9,726
Compression Ratio: 17:01
Service: Double circuit air brakes
Emergency / Parking: Spring potential brake
Auxiliary: ABS & EVB
Size and ply rating: 315-80R22.5 incl. spare wheel
Type: VR4/01D-7.5
Suspension: Non-free standing stabilization leaf spring, hydraulic shock absorber, transverse stabilizer
Type: HL7/015DS-13/4.769
Suspension: Stabilization suspension, 13pcs leaf spring (each 20mm)
Alternator: 70Amp
Starter Motor: 5.75kW
Batteries: 2 x 12V - 135AH
Gradeability @ GVM: 40% @GVM
Max Geared Road Speed: 90km/h (Limited to 80km/h)
Final Drive Ratio: 4,769
Make / Type / Size: GFX 430mm single
Operation: Single dry frictional disc, diaphragm spring, pulling type
New Vehicle: 3 years/300 000km (South Africa only)
Make/Model: 9T-1800 (N71/1C - LWB)
No Gears: 9
Synchromesh or Constant Mesh: Synchromesh
Transfer Box:N/A
P.T.O: Yes
Overall Length (OL): 7 230 (SWB) / 9 390 (LWB)
Overall Width (OW): 2 495
Overall Height (OH): 3 085
Front Overhang (FOH): 1 435
Rear Overhang (ROH): 780 (SWB) / 1 940 (LWB)
Wheel Base (WB): 4 175 (SWB) / 5 175 (LWB)
Bumper to Back of Cab (BBC):1 880
Cab to Rear Axle / unit (CA): 3735 (SWB) / 4735 (LWB)
Turning Radius (TR):8 500
Fuel Tank Capacity (FTC): 400 LTR Aluminum
Manufacturers Gross Vehicle Mass (GVM): 33 000
Manufacturers Gross Combination Mass (GCM): 43 000
Manufacturers Front Axle Mass (GA): 7 500
Manufacturers Rear Axle Mass (GAU): 26 000
Permissible Maximum Vehicle Mass (V): 25 500
Permissible Maximum Front Axle Mass (AF): 7 500
Permissible Maximum Rear Axle Mass (AR): 18 000
Unladen Front Axle Mass (UF): 4 140
Unladen Rear Axle Mass (UR): 4 540
Total Unladen Mass (UT):8 680
Permissible Max Drawing Vehicle Mass (D/T): 43 000
Day Cab: Hydraulic Tiltable Cab
SPECIFICATIONS
Additional Applications
| Models | Variant | Price |
|---|---|---|
| 3335-K 6x4 |
Chassis Tipper | R P.O.A |
| 3335 LWB 6x4 |
Chassis Cab | R P.O.A |
| 3335 10 cube Tub 6x4 |
Tipper | R P.O.A |
| 3335 10 cube Ribless 6x4 |
Tipper | R P.O.A |
| 3335 12 cube Tub 6x4 |
Tipper | R P.O.A |
| 3335 16 000L 6x4 |
Water Tanker | R P.O.A |
| 3335 17 000L 6x4 |
Water Tanker | R P.O.A |
